Icu Bed Five Functional Manual

Get a Price/Quote

Icu Bed Five Functional Manual Specification

Regional Style
Indian Style

Design
Ergonomic, Modern with Perforated Mattress Base

General Use
Medical Furniture

Height
Adjustable from 450 mm to 750 mm

Dimension (L*W*H)
2200 mm x 1000 mm x 450-750 mm

Specific Usage
ICU, Hospitals

Furniture Type
Hospital Bed

Material
Mild Steel, ABS

Metals Type
Powder Coated Steel

Folded
No

Function
Five Functional Manual Operation: Backrest, Knee Rest, Trendelenburg, Reverse Trendelenburg, Height Adjustment

Back Rest Lifting Angle
0-80 Degrees

Size
Standard ICU Bed Size

Weight
Approx. 70-90 kg

Maximum Loading
250 kg

Feature
Durable, Adjustable Height, Side Railing, Head & Foot Board Included

About Icu Bed Five Functional Manual

DESCRIPTION:

Frame Made of strong rectangular CRCA pipe
Uniformly perforated Four sectional CRCA sheet top
Back-Rest, Knee-Rest,trendelberg/Reverse Trenderberg hi- low position obtained by crank mechanism
ABS molded head and foot panels
ABS side safety railing
Bed mounted on 5 inch special casters, two with brakes
One S.S. I.V. Road
Overall Size 220L100W60-80H cm
Pretreated and epoxy powder coated

Versatile Manual Adjustability

The ICU Bed Five Functional Manual allows user-friendly operation with five key adjustments: backrest incline, knee section, Trendelenburg, reverse Trendelenburg, and height changes. Each function is operated via individual, foldable manual cranks, facilitating quick and precise positioning tailored to patient care requirements in intensive care settings.

Safety and Patient Comfort

Featuring ABS removable head and foot boards alongside collapsible aluminum side railings, the bed ensures maximum safety and ease for both patients and healthcare professionals. The ergonomic mattress platform supports pressure relief and ventilation. With integrated elements like central braking wheels and an adjustable IV pole, patient handling becomes more secure and efficient.

Sturdy, Modern Design for Hospitals

Built from mild steel and finished with an epoxy powder coating, the ICU bed offers durability and a modern Indian-style design. It accommodates up to 250 kg of patient weight, with adjustable height ranging from 450 mm to 750 mmsuitable for most hospital and ICU environments. The integrated urine bag holder and four-section platform further optimize the beds utility.

FAQs of Icu Bed Five Functional Manual:

Q: How does the five-function manual operation of the ICU bed work?

A: The bed is equipped with three separate, foldable manual cranks located at the base. Each crank individually adjusts functions such as backrest inclination, knee rest, Trendelenburg and reverse Trendelenburg positions, as well as the overall height, allowing caregivers to position patients appropriately and safely.

Q: What materials are used in the construction of the head and foot boards?

A: The head and foot boards are constructed from high-quality ABS plastic, which is both removable and easy to clean. This material offers strength, is lightweight, and aids in efficient disinfection between patient use.

Q: When should the collapsible side railings be used?

A: Collapsible aluminum side railings should be engaged when the bed is in use to prevent accidental falls or aid in patient transfer. They can be easily lowered when necessary for procedures, transfers, or during patient entry and exit from the bed.

Q: Where can this ICU bed be utilized?

A: This bed is specifically designed for intensive care units (ICU) in hospitals but can also be effectively used in wards or general medical settings where advanced patient positioning and comfort are essential.

Q: What benefits does the four-section perforated CRCA sheet platform offer?

A: The four-section perforated design improves mattress ventilation, reducing heat accumulation and promoting hygiene. Its segmented design also supports different adjustment zones for optimal patient comfort and clinical care.

Q: How does the central locking brake system enhance safety?

A: The central locking 125 mm castor wheels allow for easy and secure immobilization of the bed, ensuring it remains stable during patient care activities and transfers. This minimizes movement-related risks and helps maintain a safe environment in the ICU.
